NestJS requests to multiple services with different auth

How to handle customized @nest/axios HttpModule

NestJS is a popular backend framework built on Node.js.

Suppose your product is designed using a microservices architecture and uses NestJS for the Backend for Frontend (BFF). Due to its role, the BFF interacts with multiple services, which can include both internal servers and third-party SaaS providers. As a result, managing different types of authorizations simultaneously becomes essential.

In this article, I will share solutions for effectively handling these situations.

Sample code

https://github.com/maclt/sample-multiple-nest-http-auths

Overview

Step1. Set up customized HttpService

In this solution, we setup the customized HttpService.

Here is the example of HttpModule which use API Key to access to the backend server.

// src/common/module/apiKey.module.ts

import { Module, Global, OnModuleInit } from '@nestjs/common';
import { HttpModule, HttpService } from '@nestjs/axios';
import { ConfigService } from '@nestjs/config';

export abstract class ApiKeyHttpService extends HttpService {}

interface EnvironmentVariables {
  API_KEY: string;
}

@Global()
@Module({
  imports: [HttpModule],
  providers: [
    {
      provide: ApiKeyHttpService,
      useExisting: HttpService,
    },
  ],
  exports: [ApiKeyHttpService],
})
export class ApiKeyHttpModule implements OnModuleInit {
  constructor(
    private httpService: HttpService,
    private configService: ConfigService<EnvironmentVariables>,
  ) {}

  onModuleInit() {
    this.httpService.axiosRef.defaults.headers.common['x-api-key'] =
      this.configService.get('API_KEY');
  }
}

ApiKeyHttpService … A customized HttpService which set the x-api-key header.¹

ApiKeyHttpModule … A module which includes ApiKeyHttpService and be imported to the appModule.

Step2. use customized HttpService accordingly

As a next step, import ApiKeyHttpService into the repository, and use it according to the requirement of services.

// src/common/repository/sample.repository.ts

import { Injectable } from '@nestjs/common';
import { ApiKeyHttpService } from '../module/apiKey.module';
import { Auth0HttpService } from '../module/auth0Http.module';
import { Sigv4HttpService } from '../module/sigv4Http.modules';

@Injectable()
export class SampleRepository {
  constructor(
    private readonly apiKeyHttp: ApiKeyHttpService,
    private readonly auth0Http: Auth0HttpService,
    private readonly siv4Http: Sigv4HttpService,
  ) {}

  async getFromServerProtectedByApiKey() {
    return this.apiKeyHttp.get('https://order.api.example.com');
  }

  async getFromServerProtectedByAuth0() {
    return this.auth0Http.get('https://payment.api.example.com');
  }

  async getFromServerProtectedBySigv4() {
    return this.siv4Http.get('https://credit.api.example.com');
  }
}

In this example, the order service requires API Key while the payment service requires AWS STS.

Variations

I share the variations of the sample code

• Auth0 M2M

• AWS STS

Notes

In the sample code, I did not implement some important feature such as

• Retry to the backend servers

• Cache the credentials (access token of Auth0 / credential identity of STS)²

References

1. NestJS tip: how to inject multiple versions of the same provider into one module (e.g.: many Axios instances)

---

1. Because of how dependency injection works, if the NestJS app has only one HttpService instance, the change to the HttpService instance will be applied to all the other HTTP requests to backend services. So separated HttpService for different authorizations are necessary.

2. These tokens have throttling limits, so you cannot make infinite requests for them. You should cache them until they expire.
